Emcod 24VDC Magnetic Transformer Outdoor Phase cut Dimmable Black
Emcod 24VDC Magnetic Transformer Outdoor Phase cut Dimmable Black
Roll over image to zoom in Click on image to zoom
Emcod 24VDC Magnetic Transformer Outdoor Phase cut Dimmable BlackEmcod 24VDC Magnetic Transformer Outdoor Phase cut Dimmable Black

Emcod 24VDC Magnetic Transformer Outdoor Phase cut Dimmable Black

Emcod LightingSKU: EM600S24DC
Select Wattage: 600W 24VDC
Price:
$356.40 USD

Fast & Easy Quote Request

Select the product options and the quantity and then click the “Request A Quote” button. If you do not see the option you want, note that on the request form. You may include your lighting fixtures list and attach files.

Description

EM600S24DC Emcod 24VDC Magnetic Transformer Outdoor Phase cut Dimmable Black
Magnetic Outdoor Phase cut Dimmable
Black Powder Coated Steel Enclosure

Conforms to UL STD. 2108
Certified to CSA
STD. C22.2 № 250.0
model EM600

Electrical Parameters

Input Voltage: 120V 60Hz
Max. input current: 6A at full load
Output voltage without load: 25VDC
Output voltage fully loaded: 23.5VDC
Max. Total Wattage: 600W
Max. Output Current: 25A
Efficiency: 93%

12v & 15v Multi Tap Product Numbers:

Click for CM.TRX-75-12 & 15

Click for CM.TRX-150-12 & 15
