Lumec Lighting Zenith LED Post Top (Z12 & Z12A)
Product List
| Product Name | SKU | Watts | Lumens | Kelvin |
|---|---|---|---|---|
| Zenith (Z12), 49W, 42 LEDs, Type III, 3000K - 99 lm/W | Z12-40W42LED3K-G2-RLE3 | 49 | 4897 | 3000 |
| Zenith (Z12), 70W, 42 LEDs, Type III, 3000K - 92 lm/W | Z12-65W42LED3K-G2-RLE3 | 70 | 6501 | 3000 |
| Zenith (Z12), 49W, 42 LEDs, Type V, 3000K - 99 lm/W | Z12-40W42LED3K-G2-RLE5 | 49 | 4871 | 3000 |
| Zenith (Z12), 70W, 42 LEDs, Type V, 3000K - 92 lm/W | Z12-65W42LED3K-G2-RLE5 | 70 | 6465 | 3000 |
| Zenith (Z12), 49W, 42 LEDs, Type III, 4000K - 107 lm/W | Z12-40W42LED4K-G2-RLE3 | 49 | 5270 | 4000 |
| Zenith (Z12), 70W, 42 LEDs, Type III, 4000K - 99 lm/W | Z12-65W42LED4K-G2-RLE3 | 70 | 6995 | 4000 |
| Zenith (Z12), 49W, 42 LEDs, Type V, 4000K - 107 lm/W | Z12-40W42LED4K-G2-RLE5 | 49 | 5254 | 4000 |
| Zenith (Z12), 70W, 42 LEDs, Type V, 4000K - 99 lm/W | Z12-65W42LED4K-G2-RLE5 | 70 | 6974 | 4000 |
| Zenith (Z12A), 49W, 42 LEDs, Type III, 3000K - 99 lm/W | Z12A-40W42LED3K-G2-RLE3 | 49 | 4897 | 3000 |
| Zenith (Z12A), 70W, 42 LEDs, Type III, 3000K - 92 lm/W | Z12A-65W42LED3K-G2-RLE3 | 70 | 6501 | 3000 |
| Zenith (Z12A), 49W, 42 LEDs, Type V, 3000K - 99 lm/W | Z12A-40W42LED3K-G2-RLE5 | 49 | 4871 | 3000 |
| Zenith (Z12A), 70W, 42 LEDs, Type V, 3000K - 92 lm/W | Z12A-65W42LED3K-G2-RLE5 | 70 | 6465 | 3000 |
| Zenith (Z12A), 49W, 42 LEDs, Type III, 4000K - 107 lm/W | Z12A-40W42LED4K-G2-RLE3 | 49 | 5270 | 4000 |
| Zenith (Z12A), 70W, 42 LEDs, Type III, 4000K - 99 lm/W | Z12A-65W42LED4K-G2-RLE3 | 70 | 6995 | 4000 |
| Zenith (Z12A), 49W, 42 LEDs, Type V, 4000K - 107 lm/W | Z12A-40W42LED4K-G2-RLE5 | 49 | 5254 | 4000 |
| Zenith (Z12A), 70W, 42 LEDs, Type V, 4000K - 99 lm/W | Z12A-65W42LED4K-G2-RLE5 | 70 | 6974 | 4000 |
Product Family Details
The classically inspired design houses state-of-the-art technology and has many features that allow its appearance to be customized and personalized. By combining high-tech technology with elements of modern design, the Lumec Zenith LED post top luminaires give you great flexibility and freedom. The Zenith was specially developed for lighting large areas, such as parks, public areas, and entryways. Powered by the EcoSwap LED light engine, Zenith provides longevity and energy savings.
Benefits
- Wide selection of options and styles for greater design freedom
- Prismatic Globe provides excellent pole spacing
- Powered by the Philips EcoSwap LED light engine providing longevity and energy savings
Features
- Multiple lumen packages
- Type 3 & 5 optics available
- 4000K and 3000K color temperatures available
- Dimming driver standard
- Multiple driver options and programmed dimming options available
Applications
- Road and Street
- Bridges, Monuments, Facades
