Advantage Environmental Lighting 1ST Series 1 Light Staggered Fluorescent Strip Luminaire

No reviews

Price:
Sale price$0.00 USD

Description

Advantage Environmental Lighting 1ST Series 1 Light Staggered Fluorescent Strip Luminaire

The 1ST Series is a 1-Lamp Staggered Fluorescent Strip available in 2’ through 8’ body lengths. It was designed for surface or suspended mounting applications. Outdoor facilities, high rise garages, building exteriors, educational facilities, recreational facilities, and other intensive use environments are the perfect types of environments for our 1ST. The staggered lamp concept allows for a continuous row of illumination when ran end to end to eliminate dark spots in signs, and continuous run applications, such as cove lighting.

APPLICATIONS

The 1ST Series of Fluorescent Strips were designed to be high quality, energy efficient fluorescent fixtures for use in commercial applications, offices, government facilities, schools, and public areas.

CONSTRUCTION

The fixture is constructed of a heavy gauge cold rolled steel body. 4” offset provides even, shadow-free lighting in continuous row installations.

OPTICAL SYSTEM

White polyester polymer finish with a high reflectivity. Multiple lamp configurations. Prepainted 93% high-reflective finish for maximum light output.

ELECTRICAL SYSTEM

Standard 120-277V electronic instant start ballasts for T8 lamping, ≤10% THD. Standard 120-277V electronic program start ballasts for T5 lamping, ≤10% THD. 50-60 Hz operation. Sound rated A. Thermally protected. Automatic resetting Class P. High Power Factor. Non PCB.

MOUNTING

Surface or pendant mount, individually or in continuous rows. Sufficient knockouts are provided. Double KO access on 4 ft and longer to facilitate wiring of units for multiple ballast configurations.

LISTINGS

UL and cUL Listed. Damp location rated.

WARRANTY

1-Year Limited Warranty.
