Advantage Environmental Lighting 2ST Series 2 Light Staggered Fluorescent Strip Luminaire
The 2ST Series is a 2 Lamp Staggered Fluorescent Strip available in 2’ through 8’ body lengths. It was designed for surface or suspended mounting applications. Outdoor facilities, high rise garages, building exteriors, educational facilities, recreational facilities, and other intensive use environments are the perfect types of environments for our 2ST. The staggered lamp concept allows for a continuous row of illumination when ran end to end to eliminate dark spots in signs, and continuous run applications, such as cove lighting.
The 2ST Series of Fluorescent Strips were designed to be high quality, energy efficient fluorescent fixtures for use in commercial applications, offices, government facilities, schools, and public areas.
The fixture is constructed of a heavy gauge cold rolled steel body. 4” offset provides even, shadow-free lighting in continuous row installations.
White polyester polymer finish with a high reflectivity. Multiple lamp configurations. Prepainted 93% high-reflective finish for maximum light output.
Standard 120-277V electronic instant start ballasts for T8 lamping, ≤10% THD. Standard 120-277V electronic program start ballasts for T5 lamping, ≤10% THD. 50-60 Hz operation. Sound rated A. Thermally protected. Automatic resetting Class P. High Power Factor. Non PCB.
Surface or pendant mount, individually or in continuous rows. Sufficient knockouts are provided. Double KO access on 4 ft and longer to facilitate wiring of units for multiple ballast configurations.
UL and cUL Listed. Damp location rated.
1-Year Limited Warranty.
