Advantage Environmental Lighting BAN Wall Mount LED Prison Grade
The BAN LED combines maximum security construction with energy saving technology. The BAN utilizes one piece clamshell housing as well as security lensing and tamper resistant fasteners for impact resistance and prevent contraband concealment and unwanted fixture penetration. The BAN is ideal for confinement/security applications. Suitable for use in inmate cells, psychiatric wards, secure corridors and general population areas.
FASTENERS
Stainless steel tamper-resistant center pin TORX screws standard. Allen-head screws with center pin optional.
ELECTRICAL SYSTEM
0-10V Dimming Driver included standard. Long-life LED system rated for >100K life hours (L70 @ 25°C). Complies with federal energy efficiency standards.
OPTICAL SYSTEM
Various choice of inner and outer lenses. If additional options are needed, please consults factory.
LISTINGS
UL listed for damp locations.
FINISH
The BAN is TGIC polyester powder coated with 5-stage pre-treatment and salt spray tested: 1,000 hours; Reflectance: 92%.
HOUSING
Clamshell design combines one-piece die-formed, seamless, door-less housing which maximizes impact resistance and prevents contraband concealment and unauthorized fixture penetration.
LED
80 CRI or 90 CRI LEDs available in 2700K, 3000K, 3500K, 4000K and 5000K. Life is >100,000 hours at 70% lumen maintenance.
BACKPLATE
Die-formed blade trap (1/4" minimum) prevents contraband concealment and access. Embossed standoffs prevent distortion.
WARRANTY
5 - Year Limited Warranty.
