Advantage Environmental Lighting CAXEM10 Chicago Approved LED Exit/Stair Sign & Emergency Steel Combo

Advantage Environmental Lighting CAXEM10 Chicago Approved LED Exit/Stair Sign & Emergency Steel Combo

ILLUMINATION

• Long lasting, energy efficient white LED EXIT or STAIR sign illumination . Two 6V 5.3W adjustable Chicago approved white LED lamp heads.

ELECTRICAL

• Dual 120/277V standard.
• Charge rate/power “ON” LED indicator light and push-to-test switch for mandated code compliance testing.
• 6V sealed lead acid, maintenance-free, rechargeable battery.
• LVD (low voltage disconnect) prevents battery from deep discharge.
• Internal solid-state transfer switch automatically connects the internal battery to LED board and LED lamp heads for minimum 120 minute emergency illumination.
• Fully automatic solid-state, two rate charger initiates battery charging to recharge a discharged battery in 24 hours.

MOUNTING

• Mounting canopy included for top or end mount.
• Universal knockout pattern on back plate for wall mount

HOUSING

• Durable, powder-coated 20-guage steel construction in white or black finish.
• Single or double face configurations.

OPTIONS

• RC: Remote capacity of up to 10.0 watt

WARRANTY / LISTING

• Five year warranty on all electronics and housing. Battery prorated for two years.
• Meets UL924, NFPA 101 Life Safety Code, NEC, OSHA, Local and State Codes. UL Listed for damp locations (20°C – 50°C).
• Meets city of Chicago requirements.

Click for Spec Sheet
