Description
Advantage Environmental Lighting CB Series CCT/Wattage Selectable LED Flat Panel
The CB series is a back lit LED flat panel with selectable 3500K, 4000K, or 5000K color temperatures. Designed for recessed, surface mounting, or suspended applications.
APPLICATIONS
The CB series is perfect for offices, schools, government buildings, commercial applications, and any application that requires a quality flat panel light with adjustable color temperature.
OPTICAL SYSTEM
Color temperature selectable in 3500K, 4000K, and 5000K. >80 CRI with a lifetime rating of >50,000.
ELECTRICAL SYSTEM
0-10V dimming driver standard, 120-277VAC.
MOUNTING
This fixture is designed for recessed, surface, or suspended mounting.
LISTINGS
UL and cUL Listed. DLC listed. Independently tested to IESNA LM-79 and LM-80 specifications.
WARRANTY
5-Year Limited Warranty.
| CB14SSM: 1x4 CCT/Wattage Selectable Flat Panel Light 20W/25W/30W 3500K/4000K/5000K 125LM/W | CB22SSM: 2 x 2 CCT/Wattage Selectable Led Flat Panel Light 20W/25W/30W 3500K/4000K/5000K 125LM/W | CB24SSM: 2 x 4 CCT/Wattage Selectable Led Flat Panel Light 30W/40W/50W 3500K/4000K/5000K 125LM/W |
IES Files
Click for CB14-S(4000K)-S(20W)-M.IES
Click for CB14-S(4000K)-S(25W)-M.IES
Click for CB14-S(4000K)-S(30W)-M.IES
Click for CB22-S(4000K)-S(20W)-M.IES
Click for CB22-S(4000K)-S(25W)-M.IES
Click for CB22-S(4000K)-S(30W)-M.IES
Click for CB24-S(4000K)-S(30W)-M.IES
Click for CB24-S(4000K)-S(35W)-M.IES
Click for CB24-S(4000K)-S(40W)-M.IES
