6V/12V maintenance-free, rechargeable sealed lead acid battery (28W model).
Offers 4.8W, 7.8W, 20.8W of remote capacity (6V/12V DC output) standard on the 12W, 15W and 28W models.
Internal solid-state transfer switch automatically connects the internal battery to LED board and lamp heads for minimum 90-minute emergency illumination.
Fully automatic solid-state, two-rate charger initiates battery charging to recharge a discharged battery in 24 hours.
MOUNTING
Universal knockout pattern on back provided with gasket for watertight seal for back mount.
Polycarbonate mounting canopy included for top or end mount.
HOUSING
Housing is reinforced polycarbonate construction in white or black finish.
Corrosion-resistant enclosure with one piece, high-impact resistant, UV stabilized polycarbonate lens and molded gasket with stainless steel screws.
Knockout’s provided for conduit feed applications.
EZ snap-out Chevron directional indicators.
OPTIONS
SDT: Self-diagnostic feature performs monthly, biannual, and annual tests to ensure reliable operation and meets electrical and life safety codes.
CW: Optional internal heater and battery blanket for extreme cold temperature applications (-20°C – 50°C).
TP: Tamper-proof hardware helps discourage unauthorized access to the unit.
NH: No lamp heads attached to the unit enabling it to be used as a remote capable EXIT sign.
WARRANTY / LISTING
Five year warranty on all electronics and housing. Batteries prorated for two (lead acid) / five (NiCd) years.
Meets UL924, NFPA101 Life Safety Code, NEC, OSHA, Local and State Codes.
IP66 rated for Ingress protection.
NEMA4X rated.
UL certified for use in food service operations.
UL listed for wet locations (0°C – 50°C on 12W / 15W and 10°C - 40°C on 28W models).
