Advantage Environmental Lighting LASWDID High Performance Direct/Indirect Slotted LED Wall Mount Luminaire
The LASWDID Series is a direct/indirect slotted LED wall mount linear fixture, classically styled to fit any interior. It is available in stand alone or continuous run application minimum of 4' increments. Driven by performance and a clean aesthetic, the LASWDID series represents the ultimate in simplicity; a narrow, uniform line of light. Constructed with premium materials with industry leading technology, the LASWDID Series is available in configurable runs. The LASWDID Series integrates seamlessly with today’s modern building management systems. With virtually unlimited applications, the LASWDID Series allows architects and designers the freedom to experiment with their designs without exceeding ever decreasing energy budgets.
APPLICATIONS
The LASWDID Series were designed to be high quality, energy efficient LED fixtures for use in corridors, offices, government facilities, schools, and public areas.
CONSTRUCTION
The fixture is constructed of a heavy gauge cold rolled steel body. Units are shipped with die cast aluminum joiners installed for structural continuity and for attaching other units for continual runs or end caps. Architectural die cast chamfered aluminum ends for a complete designer look without exposed fasteners.
OPTICAL SYSTEM
White polyester polymer finish with a high reflectivity. Forward throw optics designed specifically for wall mount applications.
ELECTRICAL SYSTEM
Electronic drivers are available for 120/277V applications, 0-10V dimming standard. Long-life LED system rated for >100K life hours (L70 @ 50°C). Metal gear tray for internal LED driver. Complies with federal energy efficiency standards.
MOUNTING
The units mount to a wall bracket that compensates for uneven surfaces and allows for recessed electrical boxes. The wall brackets are 48-3/4 long and two are needed with an eight foot housing.
LISTINGS
Independently tested to IESNA LM-79 and LM-80 specifications. UL and cUL Listed. Damp location rated. Made in the USA, BAA compliant.
WARRANTY
5-Year Limited Warranty..
