Description
Advantage Environmental Lighting Remote Heads
Remote Heads Incandescent
ILLUMINATION
- Smooth thermoplastic or chrome plated metalized reflector with lens for optimal light distribution.
- Available with MR-16 halogen or wedge base incandescent lamps.
ELECTRICAL
- Powered from low voltage power source with low voltage wiring (not provided).
MOUNTING
- Universal mounting base plate included with mounting hardware.
- Distance of maximum run is determined by system voltage, wire gauge and total maximum wattage on the run.
- Suitable for wall or ceiling mount.
HOUSING
- Indoor application remote heads are injection-molded, engineering-grade, 5VA flame retardant, high-impact resistant, thermoplastic in white or black finish.
- Outdoor application remote heads are injection-molded, engineering-grade, 5VA flame retardant, high-impact resistant, thermoplastic in gray or black finish.
WARRANTY
- Five year warranty on electronics and housing
Remote Heads LED
ILLUMINATION
- Long lasting, efficient ultra-bright white LED lamp heads.
- High-performance chrome-plated metalized reflector and plastic lens (indoor applications) or glass lens (outdoor applications) for optimal light distribution.
- Adjustable LED lamp heads increases center-to-center spacing with 8 LEDs in each lamp head.
ELECTRICAL
- Powered from low voltage power source with low voltage wiring (not provided), or with a MultiVolt option.
MOUNTING
- Universal mounting base mounts to single-gang switch box.
- Distance of maximum run is determined by system voltage, wire gauge and total maximum wattage on the run.
- Suitable for wall or ceiling mount.
HOUSING
- Indoor application remote heads are injection-molded, engineering-grade, 5VA flame retardant, high-impact resistant, thermoplastic in white or black finish.
- Outdoor application remote heads are die-cast aluminum, Sealed and gasketed in gray or black finish.
WARRANTY/LISTING
- Five year warranty on electronics and housing.
- UL listed with approved Best Lighting Products.
- Meets UL924, NFPA 101 Life Safety Code, NEC,OSHA, Local and State Codes
| RHEM1616V5W: Single head Indoor MR16 remote 5 Watts | RHEM1626V5W: Double head Indoor MR16 remote 2x5 Watts | RHEM1826V54W: Dual head Indoor remote 5.4 Watts | RHEM182WP-6V72W: Double head weatherproof remote 7.2 Watts | RH19LED1R1 (9.6V): LED Combo Remote Head, Single, Indoor | RH19LED1SDTR1 (3.6V): LED R1 Remote Head, Single, Indoor |
| RH19LED1MV: LED Multi-Volt (3.6v/9.6v/12v) Remote Head, Single, Indoor | RH19LED1WPR1: LED Combo Remote Head, Plastic, Single, Wet Location | RH19LED1SDTWPR1: LED Combo Remote Head, Single, Wet Location | RH20LED2 (3.6V): LED Combo Remote Head, Double | RH20LED2R1 (9.6V): LED R1 Remote Head, Double | RH20LED2MV: LED Multi-Volt (3.6v/9.6v/12v) Remote Head, Dual, Indoor |
| RH20LED2SDTR1: LED Combo Remote Head, Plastic, Double, Wet Location | RH20LED2WPR1: LED Combo Remote Head, Double, Wet Location | RH20LED2SDTWPR1: LED R1 Remote Head, Plastic, Double, Wet Location | RHEM2116V54W: Single head Indoor remote, 5.4 Watts | RHEM2126V54W: Double head Indoor remote 2x5.4 Watts | CNXRH1W: NEMA4X/NSF LED Remote Head, 1 Head, White Housing |
| CNXRH1B: NEMA4X/NSF LED Remote Head, 1 Head, Black Housing | CNXRH1G: NEMA4X/NSF LED Remote Head, 1 Head, Grey Housing | CNXRH2W: NEMA4X/NSF LED Remote Head, 2 Heads, White Housing | CNXRH2B: NEMA4X/NSF LED Remote Head, 2 Heads, Black Housing | CNXRH2G: NEMA4X/NSF LED Remote Head, 2 Heads, Grey Housing | CNXRHTP: Tamper-Proof for NEMA4X/NSF LED Remote Head |
IES Files
Click for 12W Incandescent RH Remote Head.IES
Click for 5.4W Incandescent Wedge Base for RH Remote Heads.IES
Click for 6V 5W MR16 for Remote Heads RH.IES
Click for 7.2W Incandescent RH Remote Head.IES
Click for 9W Incandescent RH Remote Head.IES
Product Files
