Advantage Environmental Lighting WAL 7" Wrap Wired for LED Tubes
The WAL Series is a 7” Wrap wired for LED tubes available in 2’ or 4’ body lengths. It is a low-profile, narrow, 2 lamp wrap that was designed for surface mounting applications. The WAL utilizes state-of-the-art technology to deliver the highest possible efficiency in the lighting industry.
APPLICATIONS
The WAL Series of Wraps wired for LED tubes were designed to be high quality, energy efficient fixtures for use in commercial applications, industrial and garage applications, as well as kitchens, offices and storage rooms.
CONSTRUCTION
The fixture is constructed of a die-formed heavy gauge steel body. Housing embossed for maximum rigidity. Smooth hemmed sides for safe handling.
OPTICAL SYSTEM
White polyester polymer finish with a minimum 93% reflectivity. Lift-and-shift lens. Advanced micro-prism clear acrylic lens design provides excellent lamp obscuration. Linear sides provide excellent light distribution and put more light in task areas. Manufactured from durable DR/Acrylic polymer blend.
ELECTRICAL SYSTEM
120/277V applications.
MOUNTING
Unit maybe surface, stem or aircraft cable mounted individually or in continuous rows
LISTINGS
UL and cUL Listed. Damp location rated.
WARRANTY
5-Year Limited Warranty.
IES Files
Click for WAL-4-2-32-LED.IES
