Amerlux Evoke 4.75" Square Downlight Family
The Evoke® 4.75 Downlight features the fit, finish and attention to detail of the existing Evoke® line that you've loved since its introduction in 2006. With the current advancements in lighting technology Evoke® 4.75" delivers the performance, energy savings and color you expect from a spec-grade LED downlight. Suitable for a variety of lighting schemes featuring general, accent and display applications, Evoke® 4.75" gives architects and lighting designers the flexibility to complete sustainable lighting designs. Impressive performance, high lumen delivery, consistent color. Round and Square trim available.
Features & Benefits
- Wattage: 48 max
- Lumen Output: 4,290 max
- Candle Beam Center Power (CBCP): 18,990 max
- Color Temp (CCT): 2200K , 2700K , 3000K , 3500K , 4000K , Class A (Full Gamut) , Crisp White (Full Gamut)
- Color Rendering Index (CRI): 80+ , 90+
Contents
| Product |
Aperture Size |
Trim / Trimless |
Wattage |
Delivered Lumens |
| Downlight |
4.75" |
Y / Y |
13, 16, 21, 29 |
2,250 max |
| HP Downlight |
4.75" |
Y / Y |
27, 36, 42, 48 |
3,903 max |
| Adjustable |
4.75" |
Y / Y |
11, 15, 16, 18, 20, 21, 23, 30, 34 |
- |
| Lensed Downlight |
4.75" |
Y / Y |
16, 21, 30, 34, 42, 46 |
4,290 max |
| Lensed Wall Wash |
4.75" |
Y / Y |
16, 21, 30, 34, 42, 46 |
3,792 max |
