EM150S12AC Magnetic LED AC Driver Outdoor Phase cut Dimmable
Black Powder Coated Steel Enclosure.
4008104
Conforms to UL STD. 2108
Certified to CSA
STD. C22.2 № 250.0
model EM150
Link to certification
EM150S12AC Electrical Parameters
Input Voltage: 120V 60Hz
Max. input current: 1.4A at full load
Output voltage without load: 12.8VAC
Output voltage fully loaded: 11.8VAC
Max. Total Wattage: 150W
Max. Output Current: 12.5A
Efficiency: 90%
Load regulation: 0.08%
