Description

FSC Lighting FL-AOK Series - Adjustable LED Flood Light

Features

  • Applications: Ideal for use in exterior commercial and industrial building facades.
  • Construction: Housing made from die-cast aluminum. Tempered glass lens.
  • Mounting: Slip-fitter, trunnion and adjustable knuckle mounting options available
  • Electrical: Utilizes high-efficiency LED power supply and circuit boards. 120-277V & 0-10V dimming standard. 50/60HZ input frequency. 5KV Surge Protection.
  • Operating Temperature: Suitable for -40°C - 40°C Ambient
  • CRI: 70+
  • Lumen Maintenance: L70 rating of 54,000
  • Warranty: Five-year warranty. Terms and Conditions Apply.
  • Certification: UL Wet Listed. Adheres to LM79, LM80 and TM21 industry standards. DesignLights Consortium® (DLC) 5.1 Premium listed1 . IP65 Rated.
FL-S-3L-AOK-15W-3000K-AK FL-S-3L-AOK-15W-3000K-TR FL-S-3L-AOK-15W-3000K-SF FL-S-3L-AOK-15W-3000K-AK-B FL-S-3L-AOK-15W-3000K-TR-B FL-S-3L-AOK-15W-3000K-SF-B
FL-S-3L-AOK-15W-3000K-AK-W FL-S-3L-AOK-15W-3000K-TR-W FL-S-3L-AOK-15W-3000K-SF-W FL-S-3L-AOK-15W-4000K-AK FL-S-3L-AOK-15W-4000K-TR FL-S-3L-AOK-15W-4000K-SF
FL-S-3L-AOK-15W-4000K-AK-B FL-S-3L-AOK-15W-4000K-TR-B FL-S-3L-AOK-15W-4000K-SF-B FL-S-3L-AOK-15W-4000K-AK-W FL-S-3L-AOK-15W-4000K-TR-W FL-S-3L-AOK-15W-4000K-SF-W
FL-S-3L-AOK-15W-5000K-AK FL-S-3L-AOK-15W-5000K-TR FL-S-3L-AOK-15W-5000K-SF FL-S-3L-AOK-15W-5000K-AK-B FL-S-3L-AOK-15W-5000K-TR-B FL-S-3L-AOK-15W-5000K-SF-B
FL-S-3L-AOK-15W-5000K-AK-W FL-S-3L-AOK-15W-5000K-TR-W FL-S-3L-AOK-15W-5000K-SF-W FL-S-3L-AOK-22W-3000K-AK FL-S-3L-AOK-22W-3000K-TR FL-S-3L-AOK-22W-3000K-SF
FL-S-3L-AOK-22W-3000K-AK-B FL-S-3L-AOK-22W-3000K-TR-B FL-S-3L-AOK-22W-3000K-SF-B FL-S-3L-AOK-22W-3000K-AK-W FL-S-3L-AOK-22W-3000K-TR-W FL-S-3L-AOK-22W-3000K-SF-W
FL-S-3L-AOK-22W-4000K-AK FL-S-3L-AOK-22W-4000K-TR FL-S-3L-AOK-22W-4000K-SF FL-S-3L-AOK-22W-4000K-AK-B FL-S-3L-AOK-22W-4000K-TR-B FL-S-3L-AOK-22W-4000K-SF-B
FL-S-3L-AOK-22W-4000K-AK-W FL-S-3L-AOK-22W-4000K-TR-W FL-S-3L-AOK-22W-4000K-SF-W FL-S-3L-AOK-22W-5000K-AK FL-S-3L-AOK-22W-5000K-TR FL-S-3L-AOK-22W-5000K-SF
FL-S-3L-AOK-22W-5000K-AK-B FL-S-3L-AOK-22W-5000K-TR-B FL-S-3L-AOK-22W-5000K-SF-B FL-S-3L-AOK-22W-5000K-AK-W FL-S-3L-AOK-22W-5000K-TR-W FL-S-3L-AOK-22W-5000K-SF-W
FL-S-3L-AOK-28W-3000K-AK FL-S-3L-AOK-28W-3000K-TR FL-S-3L-AOK-28W-3000K-SF FL-S-3L-AOK-28W-3000K-AK-B FL-S-3L-AOK-28W-3000K-TR-B FL-S-3L-AOK-28W-3000K-SF-B
FL-S-3L-AOK-28W-3000K-AK-W FL-S-3L-AOK-28W-3000K-TR-W FL-S-3L-AOK-28W-3000K-SF-W FL-S-3L-AOK-28W-4000K-AK FL-S-3L-AOK-28W-4000K-TR FL-S-3L-AOK-28W-4000K-SF
FL-S-3L-AOK-28W-4000K-AK-B FL-S-3L-AOK-28W-4000K-TR-B FL-S-3L-AOK-28W-4000K-SF-B FL-S-3L-AOK-28W-4000K-AK-W FL-S-3L-AOK-28W-4000K-TR-W FL-S-3L-AOK-28W-4000K-SF-W
FL-S-3L-AOK-28W-5000K-AK FL-S-3L-AOK-28W-5000K-TR FL-S-3L-AOK-28W-5000K-SF FL-S-3L-AOK-28W-5000K-AK-B FL-S-3L-AOK-28W-5000K-TR-B FL-S-3L-AOK-28W-5000K-SF-B
FL-S-3L-AOK-28W-5000K-AK-W FL-S-3L-AOK-28W-5000K-TR-W FL-S-3L-AOK-28W-5000K-SF-W FL-M-10L-AOK-40W-3000K-AK FL-M-10L-AOK-40W-3000K-TR FL-M-10L-AOK-40W-3000K-SF
FL-M-10L-AOK-40W-3000K-AK-B FL-M-10L-AOK-40W-3000K-TR-B FL-M-10L-AOK-40W-3000K-SF-B FL-M-10L-AOK-40W-3000K-AK-W FL-M-10L-AOK-40W-3000K-TR-W FL-M-10L-AOK-40W-3000K-SF-W
FL-M-10L-AOK-40W-4000K-AK FL-M-10L-AOK-40W-4000K-TR FL-M-10L-AOK-40W-4000K-SF FL-M-10L-AOK-40W-4000K-AK-B FL-M-10L-AOK-40W-4000K-TR-B FL-M-10L-AOK-40W-4000K-SF-B
FL-M-10L-AOK-40W-4000K-AK-W FL-M-10L-AOK-40W-4000K-TR-W FL-M-10L-AOK-40W-4000K-SF-W FL-M-10L-AOK-40W-5000K-AK FL-M-10L-AOK-40W-5000K-TR FL-M-10L-AOK-40W-5000K-SF
FL-M-10L-AOK-40W-5000K-AK-B FL-M-10L-AOK-40W-5000K-TR-B FL-M-10L-AOK-40W-5000K-SF-B FL-M-10L-AOK-40W-5000K-AK-W FL-M-10L-AOK-40W-5000K-TR-W FL-M-10L-AOK-40W-5000K-SF-W
FL-M-10L-AOK-60W-3000K-AK FL-M-10L-AOK-60W-3000K-TR FL-M-10L-AOK-60W-3000K-SF FL-M-10L-AOK-60W-3000K-AK-B FL-M-10L-AOK-60W-3000K-TR-B FL-M-10L-AOK-60W-3000K-SF-B
FL-M-10L-AOK-60W-3000K-AK-W FL-M-10L-AOK-60W-3000K-TR-W FL-M-10L-AOK-60W-3000K-SF-W FL-M-10L-AOK-60W-4000K-AK FL-M-10L-AOK-60W-4000K-TR FL-M-10L-AOK-60W-4000K-SF
FL-M-10L-AOK-60W-4000K-AK-B FL-M-10L-AOK-60W-4000K-TR-B FL-M-10L-AOK-60W-4000K-SF-B FL-M-10L-AOK-60W-4000K-AK-W FL-M-10L-AOK-60W-4000K-TR-W FL-M-10L-AOK-60W-4000K-SF-W
FL-M-10L-AOK-60W-5000K-AK FL-M-10L-AOK-60W-5000K-TR FL-M-10L-AOK-60W-5000K-SF FL-M-10L-AOK-60W-5000K-AK-B FL-M-10L-AOK-60W-5000K-TR-B FL-M-10L-AOK-60W-5000K-SF-B
FL-M-10L-AOK-60W-5000K-AK-W FL-M-10L-AOK-60W-5000K-TR-W FL-M-10L-AOK-60W-5000K-SF-W FL-M-10L-AOK-80W-3000K-AK FL-M-10L-AOK-80W-3000K-TR FL-M-10L-AOK-80W-3000K-SF
FL-M-10L-AOK-80W-3000K-AK-B FL-M-10L-AOK-80W-3000K-TR-B FL-M-10L-AOK-80W-3000K-SF-B FL-M-10L-AOK-80W-3000K-AK-W FL-M-10L-AOK-80W-3000K-TR-W FL-M-10L-AOK-80W-3000K-SF-W
FL-M-10L-AOK-80W-4000K-AK FL-M-10L-AOK-80W-4000K-TR FL-M-10L-AOK-80W-4000K-SF FL-M-10L-AOK-80W-4000K-AK-B FL-M-10L-AOK-80W-4000K-TR-B FL-M-10L-AOK-80W-4000K-SF-B
FL-M-10L-AOK-80W-4000K-AK-W FL-M-10L-AOK-80W-4000K-TR-W FL-M-10L-AOK-80W-4000K-SF-W FL-M-10L-AOK-80W-5000K-AK FL-M-10L-AOK-80W-5000K-TR FL-M-10L-AOK-80W-5000K-SF
FL-M-10L-AOK-80W-5000K-AK-B FL-M-10L-AOK-80W-5000K-TR-B FL-M-10L-AOK-80W-5000K-SF-B FL-M-10L-AOK-80W-5000K-AK-W FL-M-10L-AOK-80W-5000K-TR-W FL-M-10L-AOK-80W-5000K-SF-W
FL-L-18L-AOK-100W-3000K-AK FL-L-18L-AOK-100W-3000K-TR FL-L-18L-AOK-100W-3000K-SF FL-L-18L-AOK-100W-3000K-AK-B FL-L-18L-AOK-100W-3000K-TR-B FL-L-18L-AOK-100W-3000K-SF-B
FL-L-18L-AOK-100W-3000K-AK-W FL-L-18L-AOK-100W-3000K-TR-W FL-L-18L-AOK-100W-3000K-SF-W FL-L-18L-AOK-100W-4000K-AK FL-L-18L-AOK-100W-4000K-TR FL-L-18L-AOK-100W-4000K-SF
FL-L-18L-AOK-100W-4000K-AK-B FL-L-18L-AOK-100W-4000K-TR-B FL-L-18L-AOK-100W-4000K-SF-B FL-L-18L-AOK-100W-4000K-AK-W FL-L-18L-AOK-100W-4000K-TR-W FL-L-18L-AOK-100W-4000K-SF-W
FL-L-18L-AOK-100W-5000K-AK FL-L-18L-AOK-100W-5000K-TR FL-L-18L-AOK-100W-5000K-SF FL-L-18L-AOK-100W-5000K-AK-B FL-L-18L-AOK-100W-5000K-TR-B FL-L-18L-AOK-100W-5000K-SF-B
FL-L-18L-AOK-100W-5000K-AK-W FL-L-18L-AOK-100W-5000K-TR-W FL-L-18L-AOK-100W-5000K-SF-W FL-L-18L-AOK-120W-3000K-AK FL-L-18L-AOK-120W-3000K-TR FL-L-18L-AOK-120W-3000K-SF
FL-L-18L-AOK-120W-3000K-AK-B FL-L-18L-AOK-120W-3000K-TR-B FL-L-18L-AOK-120W-3000K-SF-B FL-L-18L-AOK-120W-3000K-AK-W FL-L-18L-AOK-120W-3000K-TR-W FL-L-18L-AOK-120W-3000K-SF-W
FL-L-18L-AOK-120W-4000K-AK FL-L-18L-AOK-120W-4000K-TR FL-L-18L-AOK-120W-4000K-SF FL-L-18L-AOK-120W-4000K-AK-B FL-L-18L-AOK-120W-4000K-TR-B FL-L-18L-AOK-120W-4000K-SF-B
FL-L-18L-AOK-120W-4000K-AK-W FL-L-18L-AOK-120W-4000K-TR-W FL-L-18L-AOK-120W-4000K-SF-W FL-L-18L-AOK-120W-5000K-AK FL-L-18L-AOK-120W-5000K-TR FL-L-18L-AOK-120W-5000K-SF
FL-L-18L-AOK-120W-5000K-AK-B FL-L-18L-AOK-120W-5000K-TR-B FL-L-18L-AOK-120W-5000K-SF-B FL-L-18L-AOK-120W-5000K-AK-W FL-L-18L-AOK-120W-5000K-TR-W FL-L-18L-AOK-120W-5000K-SF-W
FL-L-18L-AOK-150W-3000K-AK FL-L-18L-AOK-150W-3000K-TR FL-L-18L-AOK-150W-3000K-SF FL-L-18L-AOK-150W-3000K-AK-B FL-L-18L-AOK-150W-3000K-TR-B FL-L-18L-AOK-150W-3000K-SF-B
FL-L-18L-AOK-150W-3000K-AK-W FL-L-18L-AOK-150W-3000K-TR-W FL-L-18L-AOK-150W-3000K-SF-W FL-L-18L-AOK-150W-4000K-AK FL-L-18L-AOK-150W-4000K-TR FL-L-18L-AOK-150W-4000K-SF
FL-L-18L-AOK-150W-4000K-AK-B FL-L-18L-AOK-150W-4000K-TR-B FL-L-18L-AOK-150W-4000K-SF-B FL-L-18L-AOK-150W-4000K-AK-W FL-L-18L-AOK-150W-4000K-TR-W FL-L-18L-AOK-150W-4000K-SF-W
FL-L-18L-AOK-150W-5000K-AK FL-L-18L-AOK-150W-5000K-TR FL-L-18L-AOK-150W-5000K-SF FL-L-18L-AOK-150W-5000K-AK-B FL-L-18L-AOK-150W-5000K-TR-B FL-L-18L-AOK-150W-5000K-SF-B
FL-L-18L-AOK-150W-5000K-AK-W FL-L-18L-AOK-150W-5000K-TR-W FL-L-18L-AOK-150W-5000K-SF-W

Dimensions

Version Depth Length Width Weight
Small 6.5" 4.5" 8.5" 5.25lbs
Medium 8.375" 11.00" 6.00" 12lbs
Large 10.5" 7.75" 14" 19lbs

Notes

  • Not all versions of this product may be DLC Premium qualified or DLC qualified.
  • Adjustable knuckle is only available in the small and medium size.
  • Trunnion and Slip-fitter only available in the medium and large sizes.
  • Finish Standard in dark bronze. Black and white available on special request.
  • Option only available for FL-M fixture.
  • Option only available for FL-L fixture.

Click for Spec Sheet

Small Flood Light Install Instructions

Medium Flood Light Install Instructions

Large Flood Light Install Instrucitons
