Ledalite FloatPlane Linear Wall Washer

LedaliteSKU: FLOATPLANE-WALL
Price:
$0.00 USD

Fast & Easy Quote Request For Signify Ledalite Lighting

Select the product options and the quantity and then click the “Request A Quote” button. If you do not see the option you want, note that on the request form. You may include your lighting fixtures list and attach files.
We will contact you with any questions and strive to provide you with a competitive quote as quickly as possible.

Description

Ledalite FloatPlane Linear Wall Washer

Products List

Products Watts Lumen Kelvin
FloatPlane wall, Acrylic Diffuser, 2200lm/4ft, 90 CRI, 3500K 24x8LSGAA04 18.8 2200 3500
FloatPlane wall, Acrylic Diffuser, 2200lm/4ft, 80 CRI, 5000K 24x8LEGAA04 16.4 2200 5000
FloatPlane wall, Acrylic Diffuser, 2200lm/4ft, 80 CRI, 2700K 24x8LDGAA04 16.4 2200 2700
FloatPlane wall, Acrylic Diffuser, 2200lm/4ft, 80 CRI, 3000K 24x8LCGAA04 16.4 2200 3000
FloatPlane wall, Acrylic Diffuser, 2200lm/4ft, 80 CRI, 3500K 24x8LBGAA04 16.4 2200 3500
FloatPlane wall, Acrylic Diffuser, 2200lm/4ft, 80 CRI, 4000K 24x8LAGAA04 16.4 2200 4000
FloatPlane wall, Acrylic Diffuser, 3100lm/4ft, 90 CRI, 3500K 24x8LSEAA04 28 3100 3500
FloatPlane wall, Acrylic Diffuser, 3100lm/4ft, 80 CRI, 5000K 24x8LEEAA04 24 3100 5000
FloatPlane wall, Acrylic Diffuser, 3100lm/4ft, 80 CRI, 2700K 24x8LDEAA04 24 3100 2700
FloatPlane wall, Acrylic Diffuser, 3100lm/4ft, 80 CRI, 3000K 24x8LCEAA04 24 3100 3000
FloatPlane wall, Acrylic Diffuser, 3100lm/4ft, 80 CRI, 3500K 24x8LBEAA04 24 3100 3500
FloatPlane wall, Acrylic Diffuser, 3100lm/4ft, 80 CRI, 4000K 24x8LAEAA04 24 3100 4000
FloatPlane wall, Acrylic Diffuser, 4200lm/4ft, 90 CRI, 3500K 24x8LSCAA04 38.6 4200 3500
FloatPlane wall, Acrylic Diffuser, 4200lm/4ft, 80 CRI, 5000K 24x8LECAA04 32.5 4200 5000
FloatPlane wall, Acrylic Diffuser, 4200lm/4ft, 80 CRI, 5000K 24x8LECAA04 32.5 4200 5000
FloatPlane wall, Acrylic Diffuser, 4200lm/4ft, 80 CRI, 3000K 24x8LCCAA04 32.5 4200 3000
FloatPlane wall, Acrylic Diffuser, 4200lm/4ft, 80 CRI, 3500K 24x8LBCAA04 32.5 4200 3500
FloatPlane wall, Acrylic Diffuser, 4200lm/4ft, 80 CRI, 4000K 24x8LACAA04 32.5 4200 4000
FloatPlane wall, Acrylic Diffuser + 45% Down Kit, 2200lm/4ft, 90 CRI, 3500K 24x8LSGAD04 18.8 2200 3500
FloatPlane wall, Acrylic Diffuser + 45% Down Kit, 2200lm/4ft, 80 CRI, 5000K 24x8LEGAD04 16.4 2200 5000
FloatPlane wall, Acrylic Diffuser + 45% Down Kit, 2200lm/4ft, 80 CRI, 2700K 24x8LDGAD04 16.4 2200 2700
FloatPlane wall, Acrylic Diffuser + 45% Down Kit, 2200lm/4ft, 80 CRI, 3000K 24x8LCGAD04 16.4 2200 3000
FloatPlane wall, Acrylic Diffuser + 45% Down Kit, 2200lm/4ft, 80 CRI, 3500K 24x8LBGAD04 16.4 2200 3500
FloatPlane wall, Acrylic Diffuser + 45% Down Kit, 2200lm/4ft, 80 CRI, 4000K 24x8LAGAD04 16.4 2200 4000
FloatPlane wall, Acrylic Diffuser + 45% Down Kit, 3100lm/4ft, 90 CRI, 3500K 24x8LSEAD04 28 3100 3500
FloatPlane wall, Acrylic Diffuser + 45% Down Kit, 3100lm/4ft, 80 CRI, 5000K 24x8LEEAD04 24 3100 5000
FloatPlane wall, Acrylic Diffuser + 45% Down Kit, 3100lm/4ft, 80 CRI, 2700K 24x8LDEAD04 24 3100 2700
FloatPlane wall, Acrylic Diffuser + 45% Down Kit, 3100lm/4ft, 80 CRI, 3000K 24x8LCEAD04 24 3100 3000
FloatPlane wall, Acrylic Diffuser + 45% Down Kit, 3100lm/4ft, 80 CRI, 3500K 24x8LBEAD04 24 3100 3500
FloatPlane wall, Acrylic Diffuser + 45% Down Kit, 3100lm/4ft, 80 CRI, 4000K 24x8LAEAD04 24 3100 4000
FloatPlane wall, Acrylic Diffuser + 45% Down Kit, 4200lm/4ft, 90 CRI, 3500K 24x8LSCAD04 38.6 4200 3500
FloatPlane wall, Acrylic Diffuser + 45% Down Kit, 4200lm/4ft, 80 CRI, 5000K 24x8LECAD04 32.5 4200 5000
FloatPlane wall, Acrylic Diffuser + 45% Down Kit, 4200lm/4ft, 80 CRI, 2700K 24x8LDCAD04 32.5 4200 2700
FloatPlane wall, Acrylic Diffuser + 45% Down Kit, 4200lm/4ft, 80 CRI, 3000K 24x8LCCAD04 32.5 4200 3000
FloatPlane wall, Acrylic Diffuser + 45% Down Kit, 4200lm/4ft, 80 CRI, 3500K 24x8LBCAD04 32.5 4200 3500
FloatPlane wall, Acrylic Diffuser + 45% Down Kit, 4200lm/4ft, 80 CRI, 4000K 24x8LACAD04 32.5 4200 4000
FloatPlane wall, Acrylic Diffuser + 75% Down Kit, 2200lm/4ft, 90 CRI, 3500K 24x8LSGAG04 18.8 2200 3500
FloatPlane wall, Acrylic Diffuser + 75% Down Kit, 2200lm/4ft, 80 CRI, 5000K 24x8LEGAG04 16.4 2200 5000
FloatPlane wall, Acrylic Diffuser + 75% Down Kit, 2200lm/4ft, 80 CRI, 2700K 24x8LDGAG04 16.4 2200 2700
FloatPlane wall, Acrylic Diffuser + 75% Down Kit, 2200lm/4ft, 80 CRI, 3000K 24x8LCGAG04 16.4 2200 3000
FloatPlane wall, Acrylic Diffuser + 75% Down Kit, 2200lm/4ft, 80 CRI, 3500K 24x8LBGAG04 16.4 2200 3500
FloatPlane wall, Acrylic Diffuser + 75% Down Kit, 2200lm/4ft, 80 CRI, 4000K 24x8LAGAG04 16.4 2200 4000
FloatPlane wall, Acrylic Diffuser + 75% Down Kit, 3100lm/4ft, 90 CRI, 3500K 24x8LSEAG04 28 3100 3500
FloatPlane wall, Acrylic Diffuser + 75% Down Kit, 3100lm/4ft, 80 CRI, 5000K 24x8LEEAG04 24 3100 5000
FloatPlane wall, Acrylic Diffuser + 75% Down Kit, 3100lm/4ft, 80 CRI, 2700K 24x8LDEAG04 24 3100 2700
FloatPlane wall, Acrylic Diffuser + 75% Down Kit, 3100lm/4ft, 80 CRI, 3000K 24x8LCEAG04 24 3100 3000
FloatPlane wall, Acrylic Diffuser + 75% Down Kit, 3100lm/4ft, 80 CRI, 3500K 24x8LBEAG04 24 3100 3500
FloatPlane wall, Acrylic Diffuser + 75% Down Kit, 3100lm/4ft, 80 CRI, 4000K 24x8LAEAG04 24 3100 4000
FloatPlane wall, Acrylic Diffuser + 75% Down Kit, 4200lm/4ft, 90 CRI, 3500K 24x8LSCAG04 38.6 4200 3500
FloatPlane wall, Acrylic Diffuser + 75% Down Kit, 4200lm/4ft, 80 CRI, 5000K 24x8LECAG04 32.5 4200 5000
FloatPlane wall, Acrylic Diffuser + 75% Down Kit, 4200lm/4ft, 80 CRI, 2700K 24x8LDCAG04 32.5 4200 2700
FloatPlane wall, Acrylic Diffuser + 75% Down Kit, 4200lm/4ft, 80 CRI, 3000K 24x8LCCAG04 32.5 4200 3000
FloatPlane wall, Acrylic Diffuser + 75% Down Kit, 4200lm/4ft, 80 CRI, 3500K 24x8LBCAG04 32.5 4200 3500
FloatPlane wall, Acrylic Diffuser + 75% Down Kit, 4200lm/4ft, 80 CRI, 4000K 24x8LACAG04 32.5 4200 4000
FloatPlane wall, Acrylic Diffuser + 100% Down kit, 2200lm/4ft, 90 CRI, 3500K 24x8LSGAJ04 18.8 2200 3500
FloatPlane wall, Acrylic Diffuser + 100% Down kit, 2200lm/4ft, 80 CRI, 5000K 24x8LEGAJ04 16.4 2200 5000
FloatPlane wall, Acrylic Diffuser + 100% Down kit, 2200lm/4ft, 80 CRI, 2700K 24x8LDGAJ04 16.4 2200 2700
FloatPlane wall, Acrylic Diffuser + 100% Down kit, 2200lm/4ft, 80 CRI, 3000K 24x8LCGAJ04 16.4 2200 3000
FloatPlane wall, Acrylic Diffuser + 100% Down kit, 2200lm/4ft, 80 CRI, 3500K 24x8LBGAJ04 16.4 2200 3500
FloatPlane wall, Acrylic Diffuser + 100% Down kit, 2200lm/4ft, 80 CRI, 4000K 24x8LAGAJ04 16.4 2200 4000
FloatPlane wall, Acrylic Diffuser + 100% Down kit, 3100lm/4ft, 90 CRI, 3500K 24x8LSEAJ04 28 3100 3500
FloatPlane wall, Acrylic Diffuser + 100% Down kit, 3100lm/4ft, 80 CRI, 5000K 24x8LEEAJ04 24 3100 5000
FloatPlane wall, Acrylic Diffuser + 100% Down kit, 3100lm/4ft, 80 CRI, 2700K 24x8LDEAJ04 24 3100 2700
FloatPlane wall, Acrylic Diffuser + 100% Down kit, 3100lm/4ft, 80 CRI, 3000K 24x8LCEAJ04 24 3100 3000
FloatPlane wall, Acrylic Diffuser + 100% Down kit, 3100lm/4ft, 80 CRI, 3500K 24x8LBEAJ04 24 3100 3500
FloatPlane wall, Acrylic Diffuser + 100% Down kit, 3100lm/4ft, 80 CRI, 4000K 24x8LAEAJ04 24 3100 4000
FloatPlane wall, Acrylic Diffuser + 100% Down kit, 4200lm/4ft, 90 CRI, 3500K 24x8LSCAJ04 38.6 4200 3500
FloatPlane wall, Acrylic Diffuser + 100% Down kit, 4200lm/4ft, 80 CRI, 5000K 24x8LECAJ04 32.5 4200 5000
FloatPlane wall, Acrylic Diffuser + 100% Down kit, 4200lm/4ft, 80 CRI, 2700K 24x8LDCAJ04 32.5 4200 2700
FloatPlane wall, Acrylic Diffuser + 100% Down kit, 4200lm/4ft, 80 CRI, 3000K 24x8LCCAJ04 32.5 4200 3000
FloatPlane wall, Acrylic Diffuser + 100% Down kit, 4200lm/4ft, 80 CRI, 3500K 24x8LBCAJ04 32.5 4200 3500
FloatPlane wall, Acrylic Diffuser + 100% Down kit, 4200lm/4ft, 80 CRI, 4000K 24x8LACAJ04 32.5 4200 4000


Product family information

With FloatPlane LED, it’s easier than ever to integrate sleek and sporty style into your layout and within budget. Fresh and playful, with Curve and Edge profile options, FloatPlane’s performance rivals that of high-end LED luminaires with the affordability of fluorescent. Available tunable white technology gives you the ability to vary color temperature and intensity, harmonizing lighting with your daily life.

Benefits

  • Sleek and low profile design of only 1.2"h x 8"w
  • Compelling performance of up to 129 LPW
  • Affordable as bulky fluorescent luminaires
  • Wide row spacing with fewer fixtures
  • Now available with tunable white technology

Features

  • Edge and Curve profile options
  • Multiple lumen package and color temparature options
  • Response Daylight and Actilume Occupancy with field-enabled Daylight sensors
  • Suspended and wall mount versions
  • Variable optics kits to adjust the amount of downlight required

Applications

  • Office
  • Hospitality
  • Banks
  • Fashion
Product Files

Click for FloatPlane Wall
