Lumec Lighting TownGuide LED Classic T Post Top (PBDP103)
Product List
| Product Name | SKU | Watts | Lumens | Kelvin |
|---|---|---|---|---|
| TownGuide LED Classic T Post-Top, Clear, 64 LED, Type II - 102 lm/W | PBDP103-50W64LED4K-MP-PC-C-LE2 | 50 | 5090 | 4000 |
| TownGuide LED Classic T Post-Top, Clear, 64 LED, Type III - 103 lm/W | PBDP103-50W64LED4K-MP-PC-C-LE3 | 50 | 5110 | 4000 |
| TownGuide LED Classic T Post-Top, Clear, 64 LED, Type V - 108 lm/W | PBDP103-50W64LED4K-MP-PC-C-LE5 | 50 | 5350 | 4000 |
| TownGuide LED Classic T Post-Top, Clear, 64 LED, Type II - 98 lm/W | PBDP103-61W64LED4K-MP-PC-C-LE2 | 61 | 5930 | 4000 |
| TownGuide LED Classic T Post-Top, Clear, 64 LED, Type III - 98 lm/W | PBDP103-61W64LED4K-MP-PC-C-LE3 | 61 | 5950 | 4000 |
| TownGuide LED Classic T Post-Top, Clear, 64 LED, Type V - 103 lm/W | PBDP103-61W64LED4K-MP-PC-C-LE5 | 61 | 6240 | 4000 |
| TownGuide LED Classic T Post-Top, Clear, 96 LED, Type II - 102 lm/W | PBDP103-75W96LED4K-MP-PC-C-LE2 | 75 | 7570 | 4000 |
| TownGuide LED Classic T Post-Top, Clear, 96 LED, Type III - 108 lm/W | PBDP103-75W96LED4K-MP-PC-C-LE3 | 75 | 7970 | 4000 |
| TownGuide LED Classic T Post-Top, Clear, 96 LED, Type V - 103 lm/W | PBDP103-75W96LED4K-MP-PC-C-LE5 | 75 | 7600 | 4000 |
| TownGuide LED Classic T Post-Top, Clear, 128 LED, Type II - 106 lm/W | PBDP103-95W128LED4K-MP-PC-C-LE2 | 95 | 10140 | 4000 |
| TownGuide LED Classic T Post-Top, Clear, 128 LED, Type III - 112 lm/W | PBDP103-95W128LED4K-MP-PC-C-LE3 | 95 | 10670 | 4000 |
| TownGuide LED Classic T Post-Top, Clear, 128 LED, Type V - 107 lm/W | PBDP103-95W128LED4K-MP-PC-C-LE5 | 95 | 10180 | 4000 |
| TownGuide LED Classic T Post-Top, Clear, 128 LED, Type II - 102 lm/W | PBDP103-101W128LED4K-MP-PC-C-LE2 | 102 | 10340 | 4000 |
| TownGuide LED Classic T Post-Top, Clear, 128 LED, Type III - 107 lm/W | PBDP103-101W128LED4K-MP-PC-C-LE3 | 102 | 10880 | 4000 |
| TownGuide LED Classic T Post-Top, Clear, 128 LED, Type V - 102 lm/W | PBDP103-101W128LED4K-MP-PC-C-LE5 | 102 | 10380 | 4000 |
| TownGuide LED Classic T Post-Top, Frosted, 64 LED, Type V - 68 lm/W | PBDP103-50W64LED4K-MP-PC-FO-LE5 | 50 | 3400 | 4000 |
| TownGuide LED Classic T Post-Top, Frosted, 64 LED, Type V - 65 lm/W | PBDP103-61W64LED4K-MP-PC-FO-LE5 | 61 | 3960 | 4000 |
| TownGuide LED Classic T Post-Top, Frosted, 96 LED, Type V - 63 lm/W | PBDP103-75W96LED4K-MP-PC-FO-LE5 | 75 | 4640 | 4000 |
| TownGuide LED Classic T Post-Top, Frosted, 128 LED, Type V - 71 lm/W | PBDP103-95W128LED4K-MP-PC-FO-LE5 | 95 | 6770 | 4000 |
| TownGuide LED Classic T Post-Top, Frosted, 128 LED, Type V - 73 lm/W | PBDP103-101W128LED4K-MP-PC-FO-LE5 | 102 | 7430 | 4000 |
| TownGuide LED Classic T Post-Top, Clear, 64 LED, 3000K, Type II - 90 lm/W | PBDP103-50W64LED3K-MP-PC-C-LE2 | 50.3 | 4557 | 3000 |
| TownGuide LED Classic T Post-Top, Clear, 64 LED, 3000K, Type II - 84 lm/W | PBDP103-61W64LED3K-MP-PC-C-LE2 | 61.5 | 5208 | 3000 |
| TownGuide LED Classic T Post-Top, Clear, 96 LED, 3000K, Type II - 90 lm/W | PBDP103-75W96LED3K-MP-PC-C-LE2 | 75.3 | 6787 | 3000 |
| TownGuide LED Classic T Post-Top, Clear, 128 LED, 3000K, Type II - 91 lm/W | PBDP103-95W128LED3K-MP-PC-C-LE2 | 95.4 | 8744 | 3000 |
| TownGuide LED Classic T Post-Top, Clear, 128 LED, 3000K, Type II - 90 lm/W | PBDP103-101W128LED3K-MP-PC-C-LE2 | 101.1 | 9110 | 3000 |
| TownGuide LED Classic T Post-Top, Clear, 64 LED, 3000K, Type III - 92 lm/W | PBDP103-50W64LED3K-MP-PC-C-LE3 | 50.3 | 4635 | 3000 |
| TownGuide LED Classic T Post-Top, Clear, 64 LED, 3000K, Type III - 84 lm/W | PBDP103-61W64LED3K-MP-PC-C-LE3 | 61.5 | 5214 | 3000 |
| TownGuide LED Classic T Post-Top, Clear, 96 LED, 3000K, Type III - 91 lm/W | PBDP103-75W96LED3K-MP-PC-C-LE3 | 75.3 | 6869 | 3000 |
| TownGuide LED Classic T Post-Top, Clear, 128 LED, 3000K, Type III - 91 lm/W | PBDP103-95W128LED3K-MP-PC-C-LE3 | 95.4 | 8754 | 3000 |
| TownGuide LED Classic T Post-Top, Clear, 128 LED, 3000K, Type III - 90 lm/W | PBDP103-101W128LED3K-MP-PC-C-LE3 | 101.1 | 9120 | 3000 |
| TownGuide LED Classic T Post-Top, Clear, 64 LED, 3000K, Type V - 94 lm/W | PBDP103-50W64LED3K-MP-PC-C-LE5 | 50.3 | 4743 | 3000 |
| TownGuide LED Classic T Post-Top, Clear, 64 LED, 3000K, Type V - 87 lm/W | PBDP103-61W64LED3K-MP-PC-C-LE5 | 61.5 | 5375 | 3000 |
| TownGuide LED Classic T Post-Top, Clear, 96 LED, 3000K, Type V - 93 lm/W | PBDP103-75W96LED3K-MP-PC-C-LE5 | 75.3 | 7040 | 3000 |
| TownGuide LED Classic T Post-Top, Clear, 128 LED, 3000K, Type V - 94 lm/W | PBDP103-95W128LED3K-MP-PC-C-LE5 | 95.4 | 9023 | 3000 |
| TownGuide LED Classic T Post-Top, Clear, 128 LED, 3000K, Type V - 92 lm/W | PBDP103-101W128LED3K-MP-PC-C-LE5 | 101.1 | 9401 | 3000 |
| TownGuide LED Classic T Post-Top, Clear, 64 LED, 3000K, Type II, House Side Shield - 70 lm/W | PBDP103-50W64LED3K-MP-PC-C-LE2-HS | 50.3 | 3536 | 3000 |
| TownGuide LED Classic T Post-Top, Clear, 64 LED, 3000K, Type II, House Side Shield - 65 lm/W | PBDP103-61W64LED3K-MP-PC-C-LE2-HS | 61.5 | 4042 | 3000 |
| TownGuide LED Classic T Post-Top, Clear, 96 LED, 3000K, Type II, House Side Shield - 69 lm/W | PBDP103-75W96LED3K-MP-PC-C-LE2-HS | 75.3 | 5267 | 3000 |
| TownGuide LED Classic T Post-Top, Clear, 128 LED, 3000K, Type II, House Side Shield - 71 lm/W | PBDP103-95W128LED3K-MP-PC-C-LE2-HS | 95.4 | 6786 | 3000 |
| TownGuide LED Classic T Post-Top, Clear, 128 LED, 3000K, Type II, House Side Shield - 69 lm/W | PBDP103-101W128LED3K-MP-PC-C-LE2-HS | 101.1 | 7069 | 3000 |
| TownGuide LED Classic T Post-Top, Clear, 64 LED, 4000K, Type II, House Side Shield - 73 lm/W | PBDP103-50W64LED4K-MP-PC-C-LE2-HS | 50.5 | 3724 | 4000 |
| TownGuide LED Classic T Post-Top, Clear, 64 LED, 4000K, Type II, House Side Shield - 68 lm/W | PBDP103-61W64LED4K-MP-PC-C-LE2-HS | 61.8 | 4257 | 4000 |
| TownGuide LED Classic T Post-Top, Clear, 96 LED, 4000K, Type II, House Side Shield - 73 lm/W | PBDP103-75W96LED4K-MP-PC-C-LE2-HS | 75.5 | 5546 | 4000 |
| TownGuide LED Classic T Post-Top, Clear, 128 LED, 4000K, Type II, House Side Shield - 74 lm/W | PBDP103-95W128LED4K-MP-PC-C-LE2-HS | 95.8 | 7146 | 4000 |
| TownGuide LED Classic T Post-Top, Clear, 128 LED, 4000K, Type II, House Side Shield - 73 lm/W | PBDP103-101W128LED4K-MP-PC-C-LE2-HS | 101.5 | 7445 | 4000 |
| TownGuide LED Classic T Post-Top, Clear, 64 LED, 3000K, Type III, House Side Shield - 69 lm/W | PBDP103-50W64LED3K-MP-PC-C-LE3-HS | 50.3 | 3491 | 3000 |
| TownGuide LED Classic T Post-Top, Clear, 64 LED, 3000K, Type III, House Side Shield - 64 lm/W | PBDP103-61W64LED3K-MP-PC-C-LE3-HS | 61.5 | 3989 | 3000 |
| TownGuide LED Classic T Post-Top, Clear, 96 LED, 3000K, Type III, House Side Shield - 69 lm/W | PBDP103-75W96LED3K-MP-PC-C-LE3-HS | 75.3 | 5199 | 3000 |
| TownGuide LED Classic T Post-Top, Clear, 128 LED, 3000K, Type III, House Side Shield - 70 lm/W | PBDP103-95W128LED3K-MP-PC-C-LE3-HS | 95.4 | 6698 | 3000 |
| TownGuide LED Classic T Post-Top, Clear, 128 LED, 3000K, Type III, House Side Shield - 69 lm/W | PBDP103-101W128LED3K-MP-PC-C-LE3-HS | 101.1 | 6978 | 3000 |
| TownGuide LED Classic T Post-Top, Clear, 64 LED, 4000K, Type III, House Side Shield - 72 lm/W | PBDP103-50W64LED4K-MP-PC-C-LE3-HS | 50.5 | 3676 | 4000 |
| TownGuide LED Classic T Post-Top, Clear, 64 LED, 4000K, Type III, House Side Shield - 67 lm/W | PBDP103-61W64LED4K-MP-PC-C-LE3-HS | 61.8 | 4201 | 4000 |
| TownGuide LED Classic T Post-Top, Clear, 96 LED, 4000K, Type III, House Side Shield - 72 lm/W | PBDP103-75W96LED4K-MP-PC-C-LE3-HS | 75.5 | 5474 | 4000 |
| TownGuide LED Classic T Post-Top, Clear, 128 LED, 4000K, Type III, House Side Shield - 73 lm/W | PBDP103-95W128LED4K-MP-PC-C-LE3-HS | 95.8 | 7053 | 4000 |
| TownGuide LED Classic T Post-Top, Clear, 128 LED, 4000K, Type III, House Side Shield - 72 lm/W | PBDP103-101W128LED4K-MP-PC-C-LE3-HS | 101.5 | 7348 | 4000 |
| TownGuide LED Classic T Post-Top, Frosted, 64 LED, 3000K, Type V - 60 lm/W | PBDP103-50W64LED3K-MP-PC-FO-LE5 | 50.3 | 3063 | 3000 |
| TownGuide LED Classic T Post-Top, Frosted, 64 LED, 3000K, Type V - 56 lm/W | PBDP103-61W64LED3K-MP-PC-FO-LE5 | 61.5 | 3468 | 3000 |
| TownGuide LED Classic T Post-Top, Frosted, 96 LED, 3000K, Type V - 60 lm/W | PBDP103-75W96LED3K-MP-PC-FO-LE5 | 75.3 | 4542 | 3000 |
| TownGuide LED Classic T Post-Top, Frosted, 128 LED, 3000K, Type V - 60 lm/W | PBDP103-95W128LED3K-MP-PC-FO-LE5 | 95.4 | 5768 | 3000 |
| TownGuide LED Classic T Post-Top, Frosted, 128 LED, 3000K, Type V - 59 lm/W | PBDP103-101W128LED3K-MP-PC-FO-LE5 | 101.1 | 6009 | 3000 |
Product Family Details
Lumec TownGuide LED Post-Top luminaires meet specifications without compromising your budget. With a wide choice of designs and unbeatable value, TownGuide is ideal for any urban project. TownGuide is available in three modern shapes: Flat Cone, Classic Cone and Classic T. Each offers configuration options including clear or frosted bowls, and a range of lumen packages, so it's easy to select the right solution to suit new lighting applications or seamlessly blend into existing areas. In addition to style options, TownGuide helps to minimize wasted light and energy, and also maximizes total cost of ownership, to reduce overall costs while complying with applicable lighting requirements.
Benefits
- Increased visual comfort
- Design flexibility
- Suitable for new installations or one-to-one replacements
- Protected against moisture, dust and insects
- Maximizes total cost of ownership
Features
- State-of-the-art mid-power LEDs
- Modular solution
- Available with a frosted or clear globe
- IP66 rated
- Compatible with a range of control solutions
Applications
- Bridges, Monuments, Facades
- Road and Street
