LuxR Lighting HUN1050DALI Driver

The HUNZA HUN1050DALI/EN is a 50 Watt electronic, constant current, Remote driver available to power the M2 and M4 LuxR series version fixtures. It includes a DIP-SWITCH control system that enables the unit to be set at a range of current outputs from 500mA to 1050mA. 1-10v and Dali dimmable.

For exterior use, it is highly recommended to install this in a weatherproof box, available as an option from LuxR. The PC-17-02 weatherproof box is a requirement for UL compliance.

When this driver is used as a Remote power supply, SERIES WIRING is required to connect the fixtures. Please refer to the wiring diagram overleaf.

Specifications

• Input Voltage: 99-264VAC 50-60Hz, 170-280VDC
• Output Voltage: 0V-74VDC (depending on DIP-SWITCH setting)
• Output Current: 350 - 1050mA (depending on DIP-SWITCH setting)
• Wattage: 25W - 50W (depending on DIP-SWITCH setting)
• Temperature range: -25...+50C, max 85C
• Dimensions: 22x79x124mm (7/8" x 3 1/8" x 4 7/8" )
• Standards: P20, RCM (C-Tick), EN, CE, CSA, UL Recognized
• Ordering Code: HUN1050DALI/EN
• Ingress Protection Rating: IP20
• Compatibility: Modux: Micro, 1, 2 or 4 products
• Warranty: Warranty 5 years

Click for HUN1050DALI.pdf
