Description
SLG Lighting Architectural Full Cutoff Wall Pack
TheWFV Architectural Full Cutoff Wall Pack Gen 1 is the perfect mix of architectural styling and energy savings. This wall pack has a modern, low-profile design that can be easily customized to fit every building's design aesthetic. Available in small and medium sizes, this wall pack delivers 3,600 to 13,800 lumens with a wide, uniform distribution.
Applications:
Security Lighting, Perimeter Lighting, Building Entrances, Walkways, etc.
Specifications
- Product Series: Performance
- Wattage: 27W, 45W, 70W, 100W
- Lumen Output: 3600 Lm, 5800 Lm, 9100 Lm, 13400 Lm
- Correlated Color Temperature (CCT): 4000K, 5000K
- Color Rendering Index (CRI): 80
- Product Lens: UV stabilized optical grade polymer refractor lenses
- Control: Motion Sensor , Photocell, Avi-On Wireless
- Accessories: Motion Sensor , Button Photocell , Wireless Controls, Surge Protector, Emergency Backup Kit
- Mounting Type: Wall Mount
- Environment: Indoor & Outdoor
- Shape: Rectangle
- Product Sizes: 8.8in x 7.2in x 4.6in, 14.2in x 7.4in x 4.6in
- Listings: UL, DLC Premium
- IP Rating: IP65
- Product Type: Wall Pack
- Generation: G1
- Color & Finish: Dark Bronze
- Housing: Sealed die-casting aluminum
- Light Source: LED - Static
- Voltage Rating: Standard 120-277V
- Warranty: 10 Year
- Labor Warranty: Yes
Product Files
Click for WFV G1 Architectural Full Cutoff Wall Pack Spec Sheet
Click for WFV G1Architectural Full Cutoff Wall Pack Installation Guide
