Hadco RSS2 Polycarbonate Step Light

Hadco Lighting

Mfg ID #: RSS2-A-K5-I-E

  • $264.47
  • Save $284

Ships within 4-6 weeks

Free Shipping on orders over $150.00

SAVE 7% TODAY! on selected lights by Hadco Lighting. Limited Time Only.

Quantity DISCOUNTS (Click the "Help (?)" button)

The RSS2 is a line voltage step light perfect for high pedestrian traffic and plant life applications. The RSF2 is available die-cast aluminum faceplate with galvanized steel, single gang recessed box The optical assembly includes clear UV stabilized injection molded polycarbonate with 45 degree. Available in black and bronze. Symmetric Reflector is specular aluminum formed Reflector.

Features

  • Cool external temperatures
  • Corrosion resistant
  • Ability to shield the light source
  • Cast aluminum and bronze construction
  • Symmetric reflector
  • Silicone gasketing

Specifications

  • Housing: Die-cast aluminum faceplate with galvanized steel, single gang recessed box with stainless steel fasteners. Die-cast aluminum back box contains less than 0.3% copper to prevent corrosion in concrete or masonry applications. Gasketing is silicone. Fasteners are 300 series stainless steel. Note: Recessed housing contains four (4) 1/2" NPS conduit inlets (two (2) on bottom and one on each side) and internal pull-through wiring compartment. Die-cast aluminum trim ring contains less than 0.3% copper to resist corrosion.
  • Lamping: 18W CFL3W CFL0 (4KV porcelain mini-can base). Lower wattage lamps are acceptable.
  • Electrical Assembly: 4kv rated porcelain mini-can base. Nickel-plated screw shell with center contact. 18W Fluorescent is a GX24q-2 socket.
  • Certifications: ETL listed to U.S. safety standards for wet locations. cETL listed to Canadian safety standards for wet locations. Manufactured to ISO 9001:2008 Standards. ADA Compliant when used in indoor and outdoor wall applications.
  • Optical Assembly: Specular aluminum formed reflector. Clear UV stabilized injection molded polycarbonate with 45° louvered screen insert.
  • Height: 3.5 Inch
  • Width: 9 Inch
  • Max Weight (Text Format): 3.75 lb.
  • Warranty: Three-year limited warranty.
Spec Sheets

Click for product spec sheet

...Read More


The RSS2 is a line voltage step light perfect for high pedestrian traffic and plant life applications. The RSF2 is available die-cast aluminum faceplate with galvanized steel, single gang recessed box The optical assembly includes clear UV stabilized injection molded polycarbonate with 45 degree. Available in black and bronze. Symmetric Reflector is specular aluminum formed Reflector.

Features

  • Cool external temperatures
  • Corrosion resistant
  • Ability to shield the light source
  • Cast aluminum and bronze construction
  • Symmetric reflector
  • Silicone gasketing

Specifications

  • Housing: Die-cast aluminum faceplate with galvanized steel, single gang recessed box with stainless steel fasteners. Die-cast aluminum back box contains less than 0.3% copper to prevent corrosion in concrete or masonry applications. Gasketing is silicone. Fasteners are 300 series stainless steel. Note: Recessed housing contains four (4) 1/2" NPS conduit inlets (two (2) on bottom and one on each side) and internal pull-through wiring compartment. Die-cast aluminum trim ring contains less than 0.3% copper to resist corrosion.
  • Lamping: 18W CFL3W CFL0 (4KV porcelain mini-can base). Lower wattage lamps are acceptable.
  • Electrical Assembly: 4kv rated porcelain mini-can base. Nickel-plated screw shell with center contact. 18W Fluorescent is a GX24q-2 socket.
  • Certifications: ETL listed to U.S. safety standards for wet locations. cETL listed to Canadian safety standards for wet locations. Manufactured to ISO 9001:2008 Standards. ADA Compliant when used in indoor and outdoor wall applications.
  • Optical Assembly: Specular aluminum formed reflector. Clear UV stabilized injection molded polycarbonate with 45° louvered screen insert.
  • Height: 3.5 Inch
  • Width: 9 Inch
  • Max Weight (Text Format): 3.75 lb.
  • Warranty: Three-year limited warranty.
Signify North America Corporation (“Signify”) warrants to the original
purchaser (“Purchaser”) that the Signify branded outdoor professional
luminaires identified on Schedule 1 (“Products”) will be free from
defects in material and workmanship which cause the Product to fail
to operate in accordance with the performance specifications set
forth in documentation published for or provided with the Product
(“Specifications”) for the applicable period and subject to the additional
terms and conditions set forth on Schedule 1 from the date of purchase
(as set forth in the applicable invoice) (“Warranty Period”).
Product Line
Product LineLEDNon-LEDSpecial Conditions
Hadco Landscape and
Residentia
5 Years3 YearsLandscape Products: Warranty Period for all grade mounted composite luminaires, copper
luminaires and transformers is 10 years. Lifetime warranty offered on the finish for all cast
bronze and stainless steel housing.
Residential Products: Lifetime warranty offered on the finish to all original Purchasers on
residential lighting fixtures and posts.
